本文档介绍了如何利用YOLOv5模型训练车牌识别功能，并通过Flask框架搭建一个RESTful API接口，实现将检测到的数据和图片传输给前端。文章详细阐述了后端Python代码的实现细节，包括模型加载、图像处理、目标检测、车牌识别以及结果编码与返回。同时，也展示了基于Vue3和Element Plus的前端如何调用该API，上传图片并展示检测结果，包括识别到的车牌信息和标注了车牌的原始图片。整个流程展示了一个完整的车牌识别应用开发过程，强调了前后端协同工作的实现方法。

🚗 **后端API搭建**：文章的核心在于使用Flask框架构建了一个RESTful API，用于暴露YOLOv5车牌识别模型。通过`restapi.py`文件，实现了模型加载、图像处理、车牌识别算法（`de_lpr`和`dr_plate`）的集成，并支持将检测结果（包括车牌信息和标注后的图片）以JSON格式返回。API通过`/yolo/lprnet`接口接收前端上传的Base64编码图片，并返回处理后的数据。

🖼️ **前端图片上传与展示**：前端采用Vue3和Element Plus组件库，提供了一个用户友好的界面。用户可以通过`UploadImgs`组件上传图片，并将图片转换为Base64格式发送给后端API。后端返回的检测结果（包括车牌号和带有标注的车牌框的图片）会实时显示在前端页面上，并支持图片放大预览功能。

⚙️ **模型训练与部署**：首先，需要使用`train.py`脚本训练YOLOv5模型，生成权重文件（例如`runs/train/exp9/weights/best.pt`）。训练完成后，将模型部署到Flask后端。文章中展示了后端代码中如何指定训练好的权重文件路径，并进行模型推理，实现车牌检测和识别。

🌐 **跨域问题处理**：为了解决前端（如`http://localhost:8080`）与后端（如`http://localhost:5000`）之间的跨域请求问题，后端Flask应用通过`flask_cors`库进行了配置。允许来自特定域名的GET和POST请求，并指定了允许的请求头，确保了前后端通信的顺畅。

💡 **数据传输与格式**：前后端之间的数据传输采用了JSON格式。前端将图片以Base64编码的形式传递给后端，后端在完成检测后，将包含车牌号码、置信度、检测框坐标以及Base64编码的标注图片等信息打包成JSON对象返回给前端，实现数据的有效交互。

总结：

根据上篇文章使用train.py训练好权重文件后，再使用flask搭建后台接口，把检测的数据和图片传给前端，目前只支持监测图片

1. 与官方提供的restapi.py类似，创建一个py文件

# YOLOv5 🚀 by Ultralytics, GPL-3.0 license"""Run a Flask REST API exposing one or more YOLOv5s models"""import argparseimport ioimport numpy as npfrom flask import Flask, request, jsonifyfrom PIL import Imagefrom utils.dataloaders import IMG_FORMATS, VID_FORMATS, LoadImages, LoadScreenshots, LoadStreamsimport osimport cv2import torchfrom pathlib import Pathimport sysfrom models.common import DetectMultiBackendfrom utils.general import (check_img_size,increment_path, non_max_suppression, scale_boxes)from utils.plots import Annotator, colorsfrom utils.torch_utils import select_device, time_syncimport jsonimport base64from lprr.plate import de_lpr,dr_platefrom flask_cors import CORSimport timeapp = Flask(__name__)# 解决前端跨域问题CORS(app, resources={    r"/yolo/*": {        "origins": "http://localhost:8080",  # 允许的域名        "methods": ["GET", "POST"],          # 允许的 HTTP 方法        "allow_headers": ["Content-Type", "Authorization"],  # 允许的请求头        "supports_credentials": True,         # 允许携带 Cookie        "allow_headers": ["Content-Type", "Authorization", "access-token"]  # 添加 access-token    }})models = {}DETECTION_URL = "/yolo/lprnet"FILE = Path(__file__).resolve()ROOT = FILE.parents[0]  # YOLOv5 root directoryif str(ROOT) not in sys.path:    sys.path.append(str(ROOT))  # add ROOT to PATHROOT = Path(os.path.relpath(ROOT, Path.cwd()))  # relativedef save_base64_to_jpg(base64_string, output_path):    # 1. 解码Base64字符串    image_data = base64.b64decode(base64_string)    # 2. 转换为OpenCV图像    nparr = np.frombuffer(image_data, np.uint8)    img = cv2.imdecode(nparr, cv2.IMREAD_COLOR)    # 3. 保存为JPG    cv2.imwrite(output_path, img)class Camera():    @staticmethod    def frames(url):        weights = ROOT / 'runs/train/exp9/weights/best.pt'  # 训练好的权重路径        imgsz = 640  # 模型输入图像尺寸        device = select_device(0)  # 0 or 0,1,2,3 or cpu 没有gpu的记得改为cpu        model = DetectMultiBackend(weights, device=device, dnn=False, data=ROOT / 'data/plate.yaml')        stride, names, pt, jit, onnx, engine = model.stride, model.names, model.pt, model.jit, model.onnx, model.engine        # 检查输入尺寸是否满足模型要求        imgsz = check_img_size(imgsz, s=stride)  # check image size        vid_path, vid_writer = [None], [None]        half = False  # 半精度开关        # 仅在有GPU且格式支持时启用        half &= (pt or jit or onnx or engine) and device.type != 'cpu'  # FP16 supported on limited backends with CUDA        if pt or jit:            # 转换模型精度            model.model.half() if half else model.model.float()        dataset = LoadImages(url, img_size=imgsz)        # #创建空白图像        img = torch.zeros((1, 3, imgsz, imgsz), device=device)  # init img        _ = model(img.half() if half else img) if device.type != 'cpu' else None  # run once        for path, img, im0s, vid_cap, s in dataset:                img = torch.from_numpy(img).to(device)                img = img.half() if half else img.float()  # uint8 to fp16/32                img /= 255.0  # 0 - 255 to 0.0 - 1.0                if img.ndimension() == 3:                    img = img.unsqueeze(0)                # Inference                t1 = time_sync()                pred = model(img, augment=False, visualize=False)                # nms                pred = non_max_suppression(pred, conf_thres=0.25, iou_thres=0.45, classes=None, agnostic=False,                                           max_det=1000)                t2 = time_sync()                for i, det in enumerate(pred):  # detections per image                        # p, s, im0 = path, '', im0s                        p, im0, frame = path, im0s.copy(), getattr(dataset, 'frame', 0)                        p = Path(p)  # to Path                        save_path = str('./data/' + p.name)                        s += '%gx%g ' % img.shape[2:]                        gn = torch.tensor(im0.shape)[[1, 0, 1, 0]]                        annotator = Annotator(im0, line_width=3, example=str(names))                        if det is not None and len(det):                            results = []                            det[:, :4] = scale_boxes(img.shape[2:], det[:, :4], im0.shape).round()                            for c in det[:, -1].detach().unique():                                n = (det[:, -1] == c).sum()                                s += '%g %s, ' % (n, names[int(c)])                            for *xyxy, conf, cls in det:                                if float(conf) > 0.65:                                    # 车牌识别函数                                    plate = de_lpr(xyxy, im0)                                    # 画车牌边框                                    plateNum = dr_plate(im0, xyxy, plate)                                    label = '%s %.2f' % (names[int(cls)], conf)                                    class_name = model.names[int(cls)]                                    results.append({                                        "xmin": int(xyxy[0]),                                        "ymin": int(xyxy[1]),                                        "xmax": int(xyxy[2]),                                        "ymax": int(xyxy[3]),                                        "confidence": float(conf),                                        "class": class_name,                                        "plate": plateNum,                                    })                                    c = int(cls)                                    # 这边是画出车牌边框和置信度                                    # annotator.box_label(xyxy, label, color=colors(c, True))                                    # cv2.imwrite(save_path, im0)                        # rendered_img = im0.render()[0]  # 获取带标注的图片                        # 3. 实时编码返回                        _, buffer = cv2.imencode('.jpg', im0)                        imgData =  base64.b64encode(buffer).decode('utf-8')                        results.append({                            "imgUrl": imgData                        })                        res = {                            "data": results,                            "code": 200                        }                        # 传给前端的数据                        return jsonify(res)                        # print('%sDone. (%.3fs)' % (s, t2 - t1))                        # Save results (image with detections)                        # if True:                        #     if dataset.mode == 'image':                        #         cv2.imwrite(save_path, im0)                        #     else:  # 'video' or 'stream'                        #         if vid_path[i] != save_path:  # new video                        #             vid_path[i] = save_path                        #             if isinstance(vid_writer[i], cv2.VideoWriter):                        #                 vid_writer[i].release()  # release previous video writer                        #             if vid_cap:  # video                        #                 fps = vid_cap.get(cv2.CAP_PROP_FPS)                        #                 w = int(vid_cap.get(cv2.CAP_PROP_FRAME_WIDTH))                        #                 h = int(vid_cap.get(cv2.CAP_PROP_FRAME_HEIGHT))                        #             else:  # stream                        #                 fps, w, h = 30, im0.shape[1], im0.shape[0]                        #             save_path = str(                        #                 Path(save_path).with_suffix('.mp4'))  # force *.mp4 suffix on results videos                        #             vid_writer[i] = cv2.VideoWriter(save_path, cv2.VideoWriter_fourcc(*'mp4v'), fps,                        #                                             (w, h))                        #             vid_writer[i].write(im0)                        # cv2.namedWindow('img', cv2.WINDOW_NORMAL)                        # cv2.imshow('img', im0)                        # cv2.waitKey(0)@app.route(DETECTION_URL, methods=['POST'])def predict():    # print(model)    if request.method != 'POST':        return    if request.data:        camera_tool = Camera()        json_str = request.data.decode('utf-8')  # 或使用 response.content.decode('utf-8')        # 步骤2：解析JSON        imgFiles = json.loads(json_str).get("imgFiles")[0]        timestamp_ms = int(time.time() * 1000)        url = f"./uploadImg/{timestamp_ms}.jpg"        save_base64_to_jpg(imgFiles, url)        print(url,'request.data')        return camera_tool.frames(url)    if request.files.get('image'):        # Method 1        # with request.files["image"] as f:        #     im = Image.open(io.BytesIO(f.read()))        # Method 2        im_file = request.files['image']        im_bytes = im_file.read()        im = Image.open(io.BytesIO(im_bytes))        # if model in models:        #     results = models[model](im, size=640)  # reduce size=320 for faster inference        #     return results.pandas().xyxy[0].to_json(orient='records')if __name__ == '__main__':    app.run(host='0.0.0.0', port=5000)  # debug=True causes Restarting with stat

2. 使用vue3全家桶搭建的前端，前端页面简单写了一下，使用element-plus的upload组件封装的


这是前端获取的数据结构

前端axios请求示例，前端传过去的是一个base64格式的图片

前端展示效果
